Autel AVM Target and Bracket for Toyota (CSC0804-03)

The Autel CSC0804-03 is the OEM-specified Around View Monitor (AVM) target and bracket for Toyota vehicles within the Autel ADAS calibration ecosystem. If your shop does bumper work, camera R&R, or suspension repairs on Toyota trucks, SUVs, and sedans, this is the target assembly that gets the surround-view system calibrated correctly before you hand the keys back to the customer.

AVM systems stitch together feeds from four cameras — front, rear, and both side mirrors — into a single bird's-eye view. When any one of those cameras is disturbed, the stitch lines no longer align and the composite image is wrong. The vehicle's computer needs each camera re-aimed to factory spec using the correct target pattern at the correct position. Using the wrong target, or a generic substitute, produces calibration data that looks successful on the screen but leaves the system misaligned in real-world use.

What This Target Does

• Toyota-specific AVM pattern: Designed to match the exact checkerboard or feature pattern that Toyota's AVM calibration routine expects. The diagnostic software keys on specific visual markers — wrong pattern means the routine either errors out or, worse, passes with bad data.
• Rigid bracket mount: The bracket positions the target at the vehicle-specific height and angle required by Autel's CSC frame setup guide for Toyota. Bracket stability matters — any flex or tilt introduces error into the calibration result.
• CSC frame compatible: Mounts directly to the Autel Calibration Standard Component (CSC) frame. If you already run the MaxiSYS ADAS system with a CSC frame, this target drops in without additional hardware.
• Pairs with MaxiSYS software: Works with the MaxiSYS Ultra, MS909, MS919, and Elite II tablets running Autel ADAS software. The software guides the technician through target placement, confirms positioning, and executes the camera re-learn.

When Does a Shop Need This?

• Bumper replacement or repair: Rear and side AVM cameras are mounted in or near bumper fascias and mirror housings. Any R&R of those panels requires AVM recalibration.
• Mirror housing replacement: Side cameras on Toyota models are integrated into the mirror housing. Replacing a mirror housing — even if the camera itself wasn't swapped — typically requires recalibration.
• Collision repair: Frame pulls, suspension realignment, and any work that changes the vehicle's geometry relative to camera mounting points.
• Camera replacement: Direct swap of any AVM camera unit.
• Post-alignment checks: Some Toyota models flag AVM recalibration after significant alignment corrections.

Toyota Coverage

This target covers Toyota models that use Autel-supported AVM calibration procedures. Exact model-year and trim coverage depends on your MaxiSYS software subscription. Contact us at 866-217-0063 to confirm coverage for a specific Toyota model before purchasing.

What's in the Box

• AVM calibration target panel (Toyota-specific pattern)
• Mounting bracket for CSC frame
• Mounting hardware

Note: The CSC calibration frame is sold separately. This is a component target intended for shops already equipped with the Autel ADAS CSC frame system.

Configuration Fit

• Right for your shop if: You already run Autel ADAS with a CSC frame and need to add Toyota AVM to your calibration menu.
• Not what you need if: You don't have a CSC frame yet — start with the MaxiSYS ADAS complete kit, then add vehicle-specific targets like this one.
